MonoblocAD-CY01
Mini All-in-One Condensate Pump
Pump body and reservoir combined in a single 132 mm unit for wall-mounted, ducted and cabinet systems.
- 15 L/h
- 15 m
- ≤16 dB(A)
- IP66
Condensate pumps for HVAC-R professionals
Condensate management, engineered to disappear.
Aqualis designs compact, quiet and dependable condensate pumps for air conditioning and refrigeration. Four references that install fast, run silently and protect every installation.
100–240 VAC universal supply24-month warrantyComplete installation kits
≤ 16 dB(A)at 1 m
15 mdischarge head
3 Asafety contact
16dB(A)
Maximum sound level at 1 m on lifting pumps
15m
Maximum discharge head
24L/h
Maximum flow rate (AD-GE01)
IP67
Resin-sealed pump body (AD-BU01)
The range
Four references. Every installation covered.
From the ultra-compact monobloc to condensate recovery on the outdoor unit, each Aqualis pump solves a specific installation challenge.
Monobloc
Remote reservoirAD-BU01
Two-Piece Condensate Pump
Remote reservoir and separate pump block for low ceiling voids, technical shafts and hard-to-reach units.
- 15 L/h
- 15 m
- 1 m suction
- IP67
80 × 60 trunkingAD-GE01
Corner Condensate Pump for 80 × 60 Trunking
Integrates into the corner piece of standard European 80 × 60 mm trunking. 24 L/h and a 120 mL reservoir.
- 24 L/h
- 15 m
- 120 mL
- 17 dB
Condensate recoveryAD-PS02
Condensate Misting Pump for Outdoor Units
Recovers indoor condensate and sprays it as an ultra-fine mist onto the outdoor unit to improve heat exchange.
- 12 L/h
- <21 dB
- IP66
- Anti-siphon
Product selector
The right pump for the job.
Start from the installation, not the catalogue. Compare all specifications.
Indoor unit · limited space
Lift condensate from wall-mounted, ducted or cabinet units
Choose the all-in-one AD-CY01 for the fastest fit, or the two-piece AD-BU01 when the reservoir must sit apart from the pump.
AD-CY01AD-BU01
Line set in trunkingIntegrate the pump into 80 × 60 mm trunking
The AD-GE01 sits inside the corner piece of standard European trunking, with a 24 L/h flow rate and a 120 mL reservoir.
AD-GE01
Outdoor unitReuse condensate to improve heat exchange
The AD-PS02 mists recovered condensate onto the condenser, helping the outdoor unit reject heat more efficiently.
AD-PS02
Engineering
Built for installers. Invisible to occupants.
Every design decision reduces installation time, noise and callbacks. Discover the technology.
Whisper-quiet operation
Diaphragm lifting pumps running at 16 dB(A) or less at 1 m — suitable for bedrooms, hotels and offices.
Up to 15 m discharge head
Enough head to route condensate to a distant drain, with flow rates from 12 to 24 L/h.
Smart on/off
Level detection starts and stops the pump automatically, only when water needs to be moved.
3 A safety contact
High-water detection stops the air conditioner before an overflow can cause damage.
Sealed for the job
Resin-encapsulated pump bodies rated IP66 or IP67 and ambient temperatures up to 70 °C.
Hygienic by design
Silver-ion antibacterial beads limit mould and odours in lifting-pump reservoirs.
Condensate recovery
Every drop put back to work.
The AD-PS02 collects condensate from the indoor unit and sprays it as an ultra-fine mist onto the outdoor condenser. Evaporation cools the fins, improves heat exchange and eases the load on the compressor.
- 12 L/h maximum flow rate, below 21 dB
- Mechanical float detection, anti-siphon and high-level alert
- Three status LEDs, external filter and UPS compatibility
What does a condensate pump do?
An air conditioner produces water as it dehumidifies the air. When that water cannot drain away by gravity, a condensate pump collects it and lifts it to a drain point. Aqualis lifting pumps deliver up to 15 m of discharge head.
Which Aqualis pump should I choose for a wall-mounted split?
The AD-CY01 is the most compact option, with body and reservoir in 132 mm. The AD-BU01 separates the reservoir from the pump for very tight spaces. If the line set runs in 80 × 60 mm trunking, the AD-GE01 fits inside the corner piece.
What is the 3 A safety contact used for?
The safety contact is wired into the air conditioner's control circuit. If the water level in the reservoir becomes too high, the contact opens and stops the unit before any overflow or water damage can occur.
Can Aqualis lifting pumps be used outside Europe?
Yes. The AD-CY01, AD-BU01 and AD-GE01 accept a universal 100–240 VAC, 50/60 Hz power supply.
What warranty applies to Aqualis products?
Aqualis products are covered by a 24-month manufacturer warranty against manufacturing defects, subject to installation in accordance with the product instructions.
How can my company become an Aqualis distributor?
Complete the distribution request form on this website or write to info@aqualis-pro.com. Our team reviews every application and replies by email.
Distribute Aqualis in your market
We work with wholesalers and specialist HVAC-R distributors who share our standards. Tell us about your business and we will get back to you by email.
